Feature
1. Supports charging and discharging maintenance for all common lithium-ion and nickel-hydrogen batteries on the market.
2. Adopts state-of-the-art charge&discharge testing technology to prevent interference with the BMS system.
3. Allows for the customization of charging and discharging rules.
4. Takes a wide voltage design and built-in multiple charging and discharging modes to meet the voltage and current requirements of various battery pack modules, ensuring safety while enhancing charging and discharging efficiency.
5. Safety Protections:
Provides warning alerts for reverse polarity, high temperature, overcurrent, fan malfunction, high voltage, and excessive current to safeguard hardware safety.
Specification
| POWER INPUT | AC90~264V |
| GROUP TERMINAL VOLTAGE ACCURACY | ≤± (0.5%FS+0.3V), resolution: 0.01V |
| SINGLE CELL VOLTAGE ACCURACY | ≤± (0.1%FS+5mV), resolution: 0.01V |
| TEST CURRENT ACCURACY | ≤± (1%FS+0.2A), resolution: 0.1A |
| CHARGING&DISCHARGING VOLTAGE RANGE | DC 2~400V |
| CHARGING CURRENT RANGE | 0~100A, maximum power 4.4kw |
| DISCHARGING CURRENT RANGE | 0~100A, maximum power 7.2kw |
| DATA COMMUNICATION | RS485 |
| DISPLAY | 10.1’’ LCD |
| CHARGING CONTROL | Constant current charging + constant voltage charging |
| DISCHARGING MODE | Constant current discharging |
| DIMENSIONS | 551*349*598 (mm) |
