Feature
1. Applicable to all new energy and fuel vehicle maintenance scenarios.
2. The high-voltage module and the low-voltage module are independent of each other, with each module providing separate protection during power output without affecting each other.
3. Low Voltage Output supports 0V-50V, 0A-15A DC output, adjusting via a knob.
4. The input circuit, high-voltage output circuit, and low-voltage output circuit all have independent protection mechanisms, capable of detecting undervoltage, overvoltage, overcurrent, and short circuit faults, and implementing corresponding protective measures.
5. High Voltage Output includes current limiting and short circuit protection and supports 50V-900V, 0A-5A DC output, adjusting via a knob.
Specification
| POWER INPUT | AC100~240V@20A | |
| HIGH VOLTAGE OUTPUT | Voltage: 50~900V | |
| Current: 0~5A | ||
| LOW VOLTAGE OUTPUT | Voltage: 0~50V | |
| Current: 0~15A | ||
| FRONT PANEL | HIGH VOLTAGE:
Voltage adjustment knob, Current adjustment knob, High voltage switch button |
|
| LOW VOLTAGE:
Current adjustment knob, Voltage adjustment knob, Low voltage start/stop button |
||
| COMMUNICATION | Bluetooth | |
| DISPLAY MODE | LED Digital Tube | |
| PROTECTION | Current limiting, short circuit protection, undervoltage protection, overvoltage protection, overtemperature protection, etc | |
| WORKING TEMPERATURE | -10~65°C | |
| DIMENSIONS | 395*315*265 (mm) | |
| WEIGHT | 11Kg | |
