Feature
2. Battery Packs support BYD and CATL.
3. Android-based Scan Tool for EV Diagnostics, and also supports expanding passenger car diagnostics with purchase.
4. Supports full functionality for all systems, including DTC reading/clearing, data stream analysis, bi-directional control, guided functions, coding, version information, etc.
5. Supports DOIP/CAN FD protocols.
6. Provides 37 service functions for quick and efficient diagnosis.
7. Automatically detects VIN and starts vehicle diagnostics.
8. Supports local tech-2-tech remote diagnostics via TeamViewer on PC, helping end users resolve issues and complete repairs efficiently.
9. Supports LAUNCH ACADEMY and ONLINE SUPPORT, helping users quickly learn how to use the tool.
10. Compatible with battery testers such as BST360 and TPMS tools such as TSGUN.
11. Includes 2 years of free software updates by default. FREE
Continued use possible after the free update period, with optional upgrade purchases on MALL or through pin card. OPTIONAL
Specification
| OS | Android 10.0 |
| Display | 7’’, 1024*600 |
| Battery | 6000mAh |
| CPU | 2.0GHz |
| Storage | 4+64GB |
| Camera | Rear camera |
| WIFI |
2.4GHz/5Ghz (b/g/n) |
| Interface | OBD II, Type-C |
| Operating Temperature | 0℃~40℃ |
| Storage Temperature | -20℃~70℃ |
| Dimension | 242*132*40 (mm) |
| Weight | ＜950g |
